Window-facing and outdoor deployments demand displays built for brightness and durability in ways standard panels simply cannot deliver. The 75WH80GE is engineered specifically for high ambient light signage — retail windows, storefront displays, drive-through environments, and public-facing installations where direct or reflected sunlight is a constant operational factor. At 4,000 nits sustained brightness, this display maintains visibility and colour accuracy from dawn through night, ensuring promotional content reads clearly regardless of ambient conditions.
Key Features
- 4,000 Nits Sustained Brightness: Rated for environments where standard commercial displays wash out in daylight. This brightness level ensures content remains legible and visually compelling through polarised sunglasses and under direct sunlight exposure, a critical requirement for window-facing and outdoor retail deployments.
- 4K UHD Resolution (3,840 x 2,160): Delivers sharp, detailed imagery at 75 inches across both landscape and portrait orientations. The resolution and colour depth (1.07G colour palette) support retail-grade promotional content and product photography without degradation, particularly important when viewing distance varies in storefront environments.
- Android 14 with Built-In VisionInfo CMS: Eliminates the need for external media players or separate content management hardware. Install third-party apps directly and manage content, scheduling, and multi-display networks through the integrated cloud platform — significant operational simplification for multi-site retail or hospitality deployments.
- IP5X Environmental Rating: Protection against dust and environmental contamination. Critical for outdoor-rated installations where weather exposure and particulate matter are deployment realities. This rating supports 24/7 operation without housing enclosures in semi-exposed or sheltered outdoor settings.
- Ultra-Slim 58mm Bezel Design: Reduces installation footprint and visual intrusion in window displays or architectural spaces where bezel mass affects sightlines. The even 9.9mm frame bezel maintains visual consistency in multi-display tiled configurations.
- Ambient Light Sensor: Automatically adjusts brightness in response to changing daylight conditions, maintaining consistent visibility and reducing power consumption during low-light periods. Particularly valuable for window displays transitioning between day and night cycles.
- Efficient Power Management: Achieves 4,000 nits brightness with a maximum draw of 700W through localized LED dimming zones. Lower power consumption than comparable high-brightness panels directly reduces operational cost, especially significant in 24/7 deployments across multiple sites.
- 50,000-Hour Panel Lifespan: Rated for approximately 5.7 years at continuous 24/7 operation, establishing realistic replacement cycles for high-brightness outdoor deployments where thermal stress accelerates panel degradation.
Specifications
| Specification | Detail |
|---|---|
| Display Size | 75 inches |
| Resolution | 3,840 x 2,160 (4K UHD, 16:9) |
| Panel Type | ADS LED with DLED backlight |
| Brightness | 4,000 nits (typical) |
| Contrast Ratio | 1,200:1 (typical) |
| Colour Gamut | 72% NTSC |
| Colour Depth | 1.07 billion colours (8-bit + FRC) |
| Response Time | 9ms (typical) |
| Viewing Angles | 178° horizontal / 178° vertical |
| Refresh Rate | 60 Hz |
| Haze Rating | 1% |
| Orientations | Landscape and portrait |
| Panel Lifespan | Up to 50,000 hours |
| Operating Hours | 24/7 continuous duty |
| Operating System | Android 14 |
| Processor | ARM Cortex-A73 quad-core |
| Memory | 4GB DDR4 RAM |
| Storage | 32GB eMMC |
| Built-in Speaker | Dual 10W speakers |
| Dimensions (W × H × D) | 1,674 × 953 × 58 mm |
| Bezel Width (even) | 9.9 mm |
| Net Weight | 46.1 kg |
| VESA Mount Pattern | 600 × 600 mm |
| Power Supply | AC 100–240V, 50/60Hz |
| Maximum Power Consumption | 700W |
| Standby Consumption | <0.5W |
| Operating Temperature | 0–40°C |
| Operating Humidity | 10–80% non-condensing |
| Environmental Rating | IP5X (dust and environmental protection) |
| Certifications | CE, CB, UKCA, cTUVus, CEC, FCC, IC, ERP, RCM |
Connectivity
- HDMI 2.1: 1× HDMI 2.1 with HDCP 2.3 for high-bandwidth 4K content and future-proofing against newer professional AV sources
- HDMI 2.0: 2× HDMI 2.0 with HDCP 2.3 for legacy equipment and parallel content feeds in multi-display control scenarios
- USB: 1× USB 2.0 and 1× USB 3.0 for direct media playback, local content updates, and peripheral connectivity
- Wi-Fi: Wi-Fi 6 (802.11ax) dual-band 2.4/5.0 GHz for reliable wireless content delivery and cloud management across distributed retail locations
- Ethernet: 1× RJ45 LAN port for hardwired network connectivity and failover to wireless in retail network environments
- Bluetooth 5.4: Wireless pairing with compatible devices for remote control and mobile content streaming
- Serial Control: 1× RS232 input and 1× RS232 output (3.5mm mini-jack connectors) for integration with building management systems, HVAC triggers, and third-party display control protocols
- IR Control: 1× infrared jack for remote control compatibility and legacy AV integration scenarios
- Ambient Light Sensor Input: 1× 2.5mm sensor jack for brightness auto-adjustment feedback in daylight-responsive deployments
- Audio Output: 1× 3.5mm jack plus dual 10W built-in speakers for independent audio delivery or external amplification
