Deploying signage at scale across multiple sites requires a display that handles content scheduling without on-site intervention, adapts to changing ambient light, and survives continuous operation. The 86-inch GM50GE meets this operational reality head-on. It’s built around Android 14 with native VisionInfo cloud management, meaning your content delivery, device monitoring, and remote updates happen from a central platform—not from individual display panels. At 500 nits brightness with 25% anti-glare haze, it maintains legibility in high-traffic retail and hospitality spaces without requiring manual brightness adjustments or constant recalibration.
Key Features
- 500 Nits Brightness with Anti-Glare Coating: High brightness output ensures vibrant content visibility in daylit retail corridors, restaurant floors, and transport hubs. The 25% haze panel minimises reflections from overhead lighting and windows while preserving contrast and colour accuracy—reducing the need for content redesign or repositioning.
- 4K UHD Resolution (3840 x 2160): Sharp text rendering and detailed imagery across the full 86-inch screen supports both graphic-heavy retail promotions and information-dense corporate lobby displays. All size variants (43″ to 86″) deliver identical 4K consistency, simplifying multi-site deployments.
- Android 14 Operating System: Native app support, OTA updates, and a familiar open ecosystem reduce deployment friction. Third-party content management apps integrate directly without requiring external media players or additional hardware.
- VisionInfo Cloud Management: Centralized content scheduling, remote device monitoring, and real-time system health alerts eliminate field visits for routine updates. Deploy content changes across ten displays or a hundred without touching individual panels.
- Portrait and Landscape Orientation: Flexible installation in retail menu boards, vertical corporate directories, wayfinding signage, and standard landscape displays. All orientations maintain full 4K resolution and brightness performance.
- 18/7 Operation (126 hours per week): Extended running hours—18 hours per day, 7 days per week—support retail opening hours, hospitality busy periods, and venue operating schedules. The display remains thermally stable across this duty cycle without thermal throttling or premature panel degradation.
- Slim Bezel Design with Cable Management: 10.8mm bezels on top and sides blend seamlessly into retail environments and corporate spaces. Integrated cable routing hides power and connectivity, maintaining a polished appearance in customer-facing areas.
- ENERGY STAR 8.0 Certified: Intelligent ambient light sensor dynamically adjusts brightness in real-time, reducing power consumption during lower-light periods. Typical power draw of 205W (86″) and standby consumption under 0.5W support cost-conscious multi-site rollouts.
Specifications
| Specification | Detail |
|---|---|
| Panel Size | 86 inches (diagonal) |
| Resolution | 3840 x 2160 (4K UHD) |
| Brightness | 500 nits (typical) |
| Contrast Ratio | 1200:1 (typical) |
| Panel Type | IPS, D-LED backlit |
| Color Gamut | 72% NTSC |
| Viewing Angle | 178° horizontal and vertical |
| Anti-Glare Haze | 25% |
| Refresh Rate | 60 Hz |
| Response Time | 8 ms (typical) |
| Operating System | Android 14 |
| Processor | ARM Cortex-A73 Quad Core CPU, Mali-G57 MC1 GPU |
| Memory | 4GB DDR4 |
| Storage | 32GB eMMC |
| WiFi | WiFi 6, dual-band 2.4/5.0 GHz (802.11 a/b/g/n/ac/ax) |
| Bluetooth | BT 5.4 |
| Operating Hours | 18 hours per day, 7 days per week |
| LED Lifetime | Up to 50,000 hours |
| Orientation | Landscape and Portrait |
| Dimensions (W x H x D) | 1927.6 x 1097 x 64.6 mm (75.9 x 43.2 x 2.5 in) |
| Bezel Width | 10.8 mm (top/left/right), 11.8 mm (bottom) |
| Net Weight | 38.2 kg (84.2 lbs) |
| VESA Mount | 600 x 400 mm, 4x M6 screw |
| Power Consumption (Typical) | 205W |
| Power Consumption (Maximum) | 430W |
| Standby Consumption | Less than 0.5W |
| Power Supply | AC 100–240V, 50/60 Hz |
| Operating Temperature | 0°C to 40°C |
| Operating Humidity | 20% to 80% (non-condensing) |
| Certifications | CB, CE, cTUVus, FCC, RCM, ENERGY STAR 8.0 |
| IP Rating | IP5X |
Connectivity
- HDMI Input (x3): Two HDMI 2.0 ports and one HDMI 2.1 port for video source redundancy and future 4K 60Hz applications.
- USB-C Input (x1): PD65W power delivery enables peripheral charging and data connectivity from a single connector.
- USB-A Input (x2): One USB 2.0 and one USB 3.2 Gen1 for content loading, peripherals, and legacy device compatibility.
- Ethernet (RJ45, x1): Gigabit LAN for reliable wired network connectivity in environments where WiFi is unavailable or unreliable.
- RS232 (3.5mm, x2): One input and one output for system integration with legacy control systems, building management systems, or external scheduling hardware.
- IR Input (2.5mm, x1): Infrared sensor supports remote control operation and integration with IR-based automation systems.
- HDMI Output (x1): HDMI 2.0 output allows daisy-chaining to secondary displays or monitoring external video sources.
- Audio Output (3.5mm, x1): 3.5mm stereo jack for external amplification or routing audio to separate speaker systems in larger venues.
- Built-in Speakers (x2, 10W each): Integrated 10W stereo speakers provide ambient audio for menu displays, wayfinding announcements, and hospitality environments without requiring external audio hardware.
This display is part of our Commercial Digital Signage Displays range and integrates directly into networked signage infrastructure for multi-site deployments.
