Managing signage across multiple locations requires displays that handle continuous operation without on-site intervention. The DM66GE series addresses this by combining 4K output, remote device management through VisionInfo, and a brightness profile suited to indoor retail and hospitality environments where ambient light varies throughout the day but direct sunlight isn’t a primary concern.
Key Features
- 4K UHD Resolution with Wide Viewing Angle: 3,840 x 2,160 resolution across a 178° horizontal and vertical viewing angle means content remains clear and colour-accurate whether viewed from centre or the edges of a retail floor or waiting area—critical where customers approach from multiple angles.
- 500 Nits Brightness: Sufficient for indoor environments including retail floors, hospitality venues, and corporate spaces. The brightness maintains visual impact during peak ambient light hours without the higher power draw or cost of outdoor-grade displays.
- Anti-glare 25% Haze Panel: Minimises reflections from overhead lighting and floor-level light sources while preserving image sharpness. Reduces the “washed out” appearance that occurs when reflections compromise contrast in high-traffic retail or hospitality spaces.
- Landscape and Portrait Flexibility: Both orientations retain full 4K quality, enabling deployment as vertical menu boards in quick-service restaurants, portrait signage in retail, or landscape displays in corporate lobbies without hardware changes.
- Android 14 Operating System: Native app support and over-the-air updates reduce deployment complexity. Open ecosystem allows third-party integrations without requiring external players, lowering both hardware footprint and maintenance overhead.
- VisionInfo Cloud Management: Centralized scheduling, content updates, and device monitoring from any location eliminates the need for on-site intervention. Multi-display campaigns can be deployed, updated, or rotated across geographically dispersed locations simultaneously.
- Ultra-Narrow Bezels with Cable Management: 10.1mm bezels and integrated cable routing create a clean visual fit in retail and corporate spaces. Reduces visual clutter and installation complexity when displays are mounted edge-to-edge or in feature walls.
- Energy Efficiency with Ambient Light Sensor: Intelligent brightness adjustment responds to changes in ambient lighting throughout the day, reducing power consumption during lower-light hours. ENERGY STAR 8.0 certification confirms measurable energy performance relative to industry standards.
- 50,000-Hour LED Lifespan: At typical 18-hour daily operation, this equates to approximately 7-8 years of deployment life, aligning with common commercial refresh cycles and reducing total cost of ownership.
Specifications
| Specification | Detail |
|---|---|
| Display Size | 50 inches (diagonal) |
| Resolution | 3,840 x 2,160 (4K UHD) |
| Panel Type | IPS with D-LED backlight |
| Brightness | 500 nits (typical) |
| Contrast Ratio | 1,200:1 (typical) |
| Viewing Angle | 178° (H) / 178° (V) |
| Colour Gamut | 72% NTSC |
| Anti-glare Haze | 25% |
| Response Time | 8 ms (typical) |
| Orientation | Landscape and Portrait |
| Operating System | Android 14 |
| Processor | ARM Cortex-A73 Quad Core CPU, Mali-G57 MC1 GPU |
| Memory | 4 GB DDR4 RAM, 32 GB eMMC storage |
| Operating Hours | 7 days x 18 hours |
| LED Lifespan | Up to 50,000 hours |
| Refresh Rate | 60 Hz |
| Dimensions (W x H x D) | 1,124.1 x 644.3 x 62.5 mm |
| Weight | 11 kg (net) |
| Bezel Width | 10.1 mm (T/L/R), 10.4 mm (Bottom) |
| VESA Mount | 300 x 300 mm, 4x M6 screws |
| Power Supply | AC 100–240V, 50/60 Hz |
| Power Consumption (Typical) | 99 W |
| Power Consumption (Maximum) | 180 W |
| Standby Consumption | <0.5 W |
| Operating Temperature | 0°C to 40°C |
| Operating Humidity | 20% to 80% (non-condensing) |
| Certifications | CB, CE, cTUVus, FCC, RCM, ERP, CEC, South Africa Energy Efficiency |
| Environmental | ENERGY STAR 8.0 |
| EMC | Class B |
| Safety | IEC 62368-1 |
| IP Rating | IP5X |
Connectivity
- HDMI Inputs (x3): Two HDMI 2.0 ports and one HDMI 2.1 port allow connection of media players, PCs, or broadcast sources simultaneously. Useful for deployments where content sources rotate or backup inputs are required.
- USB Type-A (x2): One USB 2.0 and one USB 3.2 Gen1 port support external storage, peripheral device management, and firmware updates without network dependency.
- USB Type-C: Not included on 50-inch model.
- Ethernet (RJ45): Wired network connection for VisionInfo cloud management and content delivery, recommended over WiFi for reliably high-traffic retail environments.
- WiFi 6 (802.11ax): Dual-band support at 2.4 GHz and 5.0 GHz with full 802.11a/b/g/n/ac/ax compatibility enables wireless management as a secondary or primary connection option.
- Bluetooth 5.4: Supports wireless peripherals including remote controls and future accessory connectivity.
- RS-232 (Input & Output, 3.5mm): Serial control for integration with building management systems, third-party scheduling software, or legacy AV control infrastructure.
- IR Receiver (2.5mm): Accepts infrared remote control for manual brightness, volume, and input adjustment without network access.
- Audio Output (3.5mm): 3.5 mm jack for external amplification if internal 10W stereo speakers are insufficient for venue acoustics.
- HDMI Output (x1): HDMI 2.0 output allows daisy-chaining or secondary display connection in specific deployment scenarios.
The DM66GE series is part of our commercial digital signage display range, offering size and brightness options from 43 to 86 inches across consistent specifications for fleet deployments.
