Managing customer-facing displays across multiple retail or hospitality sites requires consistent content delivery without daily on-site visits. The 75GM50GE addresses this through Android 14, networked connectivity, and integrated VisionInfo cloud management—allowing content scheduling, remote updates, and centralised device monitoring from a single control point. The 500 nits brightness and 25% anti-glare panel ensure visibility in mixed ambient light, from dimly lit corporate lobbies to sunlit retail frontage.
Key Features
- 4K Resolution (3840×2160): Delivers pixel-level clarity across a 75-inch display area, critical for retail signage where legibility and visual impact must be maintained from multiple viewing distances and angles.
- 500 Nits Brightness: Maintains colour accuracy and readability in high-ambient-light environments—essential for storefront windows and interior spaces with skylights or competing light sources.
- 25% Anti-Glare Haze Coating: Reduces reflection without degrading image sharpness, ensuring critical information remains visible regardless of installation angle relative to direct light sources.
- Android 14 Operating System: Supports third-party app installation and OTA updates, allowing flexible content management workflows and avoiding locked-ecosystem constraints common in commercial displays.
- VisionInfo Cloud Management: Enables centralised scheduling, content deployment, and real-time device status monitoring across multiple displays without requiring separate management software or local intervention.
- 178° Viewing Angle (IPS Panel): Maintains colour and contrast consistency across wide horizontal and vertical viewing planes, necessary for displays positioned in high-traffic areas where viewers approach from variable angles.
- Landscape and Portrait Orientation Support: Allows flexible installation in retail menu boards, wayfinding systems, and informational displays where vertical space efficiency matters more than horizontal coverage.
- ENERGY STAR 8.0 Certification: Integrated ambient light sensor optimises brightness in real-time, reducing power consumption during lower-light periods while maintaining operational capability during peak hours.
Specifications
| Specification | Detail |
|---|---|
| Display Size | 75 inches |
| Resolution | 3840 × 2160 (4K UHD) |
| Panel Type | IPS |
| Brightness | 500 nits (typical) |
| Contrast Ratio | 1200:1 (typical) |
| Viewing Angle | 178° (horizontal & vertical) |
| Colour Gamut | 72% NTSC |
| Anti-Glare Coating | 25% haze |
| Operating System | Android 14 |
| Processor (CPU) | ARM Cortex-A73 Quad Core |
| Processor (GPU) | Mali-G57 MC1 |
| Memory (RAM) | 4GB DDR4 |
| Storage | 32GB eMMC |
| Network Connectivity | WiFi 6 (802.11ax), Dual Band (2.4/5.0 GHz), Gigabit Ethernet |
| Bluetooth | BT 5.4 |
| Orientation | Landscape & Portrait |
| Operating Hours | 18 hours per day / 7 days per week |
| LED Lifespan | Up to 50,000 hours |
| Dimensions (W×H×D) | 1676.3 × 956.6 × 64.1 mm (66.0 × 37.7 × 2.5 inches) |
| Bezel Width | 10.8 mm (top/left/right), 11.8 mm (bottom) |
| Weight (Net) | 29 kg (63.9 lbs) |
| VESA Mount | 600 × 400 mm, 4×M6 |
| Power Consumption (Typical) | 178W |
| Power Consumption (Maximum) | 390W |
| Standby Power | <0.5W |
| Operating Temperature | 0°C to 40°C |
| Operating Humidity | 20% to 80% (non-condensing) |
| Certifications | CB, CE, cTUVus, FCC, RCM, ERP, ENERGY STAR 8.0 |
Connectivity
- HDMI Inputs (3): Two HDMI 2.0 and one HDMI 2.1 port for flexible source connection and bandwidth headroom for 4K playback.
- USB-A Inputs (2): One USB 2.0 and one USB 3.2 Gen 1 for direct media insertion and device control.
- USB-C Input (1): USB Power Delivery (65W) enables peripheral charging and simplified single-cable connections.
- Gigabit Ethernet (RJ45): Wired network connection for reliable, low-latency content delivery and device management in networked signage infrastructure.
- WiFi 6 (802.11ax): Dual-band connectivity supports high-bandwidth content streaming and cloud synchronisation in congested wireless environments.
- RS-232 Input & Output (3.5mm): Legacy serial control integration for BMS automation and third-party system coordination.
- IR Input (2.5mm): Infrared receiver allows remote control operation and integration with universal control systems.
- Audio Output (3.5mm): 3.5mm jack for external amplifier connection when built-in 10W stereo speakers prove insufficient.
- HDMI Output (1): HDMI 2.0 for loop-through or secondary display connection in daisy-chain configurations.
This display integrates seamlessly into larger commercial signage solutions and networked infrastructure—explore the full range of options available across our Commercial Digital Signage Displays.
