Multi-user touch collaboration demands responsive hardware that keeps pace with group annotation and content switching without lag or dropout. The 86WM6FE combines 55-point simultaneous touch with ultra-low writing latency, 4K camera integration, and 9-device screen casting to address the practical reality of interactive classrooms and corporate meeting rooms where seamless handoff between participants and devices is fundamental to deployment success.
Key Features
- 55-point multi-user touch with ultra-low writing height: The infrared touch frame supports up to 55 simultaneous touch points with writing latency below 1.5mm, enabling natural pen annotation and group interaction without the stalling or missed input common in lower-capacity systems. This matters operationally when multiple participants are annotating the same workspace simultaneously.
- Android 13 with EDLA certification: EDLA (Enterprise Device License Agreement) certification ensures Google apps and Play Store access remain current and verified, avoiding fragmentation issues when deploying across multiple sites. The octa-core processor and 8GB RAM provide consistent performance under continuous daily use — critical in education environments where displays run 6-8 hours per day.
- Integrated 4K camera with physical shutter: Built-in 4K camera captures meeting participants and whiteboard content for hybrid attendees. Physical shutter provides explicit privacy control — essential for compliance-conscious organisations. The camera integrates with most major video conferencing platforms without additional external hardware.
- Anti-glare 9H glass surface: Reduces reflections in well-lit classrooms and meeting rooms without sacrificing image clarity. The 9H hardness rating withstands daily stylus wear and accidental surface contact, extending hardware lifespan in high-touch environments.
- 55W Dolby Atmos audio: Dual 18W + 25W speaker configuration delivers intelligible audio across large meeting rooms and classrooms without relying on external amplification. Dolby Atmos spatial processing supports video conferencing clarity — practical for hybrid and fully remote collaboration sessions.
- TÜV Rheinland blue light certification: Verified reduction in blue light emission reduces eye strain during prolonged use — a measurable consideration in education deployments where displays run continuously. This certification supports duty-of-care requirements in institutions managing fatigue-related complaints.
- Multi-protocol screen casting (9 devices simultaneous): Supports 5 different casting protocols with up to 9 devices sharing concurrently. Anti-spoofing controls prevent unauthorised casting in classroom or open meeting environments. Continuous 8-hour casting without disconnection removes the session-drop friction common in lower-end systems.
- Energy Star 8.0 certification: Delivers 321W typical consumption and optimised thermal management, reducing ongoing operational costs and lifecycle environmental impact. Relevant for facilities teams managing power budgets across multiple displays.
Specifications
| Specification | Detail |
|---|---|
| Display Size | 86 inches diagonal |
| Resolution | 3840 x 2160 pixels (4K UHD) |
| Brightness | 400 nits typical |
| Contrast Ratio | 1200:1 typical |
| Response Time | 8ms typical |
| Colour Gamut | 72% NTSC, 1.07B colours (10-bit) |
| Viewing Angle | 178° horizontal and vertical |
| Panel Lifetime | 50,000 hours minimum |
| Operating System | Android 13.0 (EDLA certified) |
| Processor | Octa-core (A73x4 @ 2.2GHz + A53x4 @ 2.0GHz) |
| GPU | Mali G52 |
| RAM | 8GB |
| Storage | 128GB internal |
| Touch Technology | Infrared touch frame, 55-point simultaneous (Android and OPS), 40-point (Mac) |
| Touch Accuracy | 90% ±1mm |
| Writing Height | Less than 1.5mm (Quatro Sense support) |
| Integrated Camera | 4K UHD with physical privacy shutter and indicator light |
| Audio Output | 61W total (18W + 18W stereo + 25W subwoofer) with Dolby Atmos |
| Physical Dimensions | 1954.7 x 1197.6 x 125.9mm (77 x 47 x 5.0 inches) |
| Weight | 59kg (130 lbs) display only |
| VESA Mount | 1000 x 600mm, 4x M8 screw holes |
| Power Input | AC 100-240V, 50/60Hz |
| Power Consumption | 321.3W typical, 430W maximum; <0.5W standby |
| Certifications | Energy Star 8.0, EDLA, CE, RCM, UKCA, FCC, cTUVus, TÜV Rheinland blue light |
| Languages Supported | English, Chinese, French, Spanish, German, Italian, Polish, Nordic, Asian, Middle Eastern, Balkan, and others (28 total) |
Connectivity
- HDMI 2.0 input x3 — supports multiple source devices with standard video switching and handoff.
- USB 3.0 x3 and USB 2.0 x1 — enables direct content transfer, peripheral control, and annotation software loading from external drives.
- Type-C x1 with 65W Power Delivery — supports modern laptops and tablets for direct casting and charging in one connection.
- Wi-Fi 802.11ax (Wi-Fi 6) dual-band — ensures stable concurrent device casting and reduces latency during screen sharing from multiple users.
- Bluetooth 5.3 — enables wireless stylus, peripherals, and proximity-based device pairing.
- NFC — supports NFC-enabled access control and device pairing protocols.
- Ethernet (1000baseT) — provides wired network backup and centralised management integration for multi-site deployments.
- Audio input and output (3.5mm and S/PDIF coaxial) — accommodates external microphones, document cameras, and audio routing to installed sound systems.
- RS-232 control (RJ45 in/out) — enables integration with room booking systems, lighting control, and AV automation infrastructure.
- OPS slot (optional) — supports passive or active OPS modules for Windows 11/10 co-execution or extended storage without display replacement.
