The Soniq ASU5517A-GA is a 55-inch commercial display rated for 50,000 hours continuous operation across retail, hospitality, and corporate signage deployments. Consumer-grade panels installed in commercial environments fail within months under 24/7 operation — this display is purpose-built to avoid that failure mode, with panel construction and power management specifications designed for always-on scheduling.
Reception Desk Digital Signage Screens for Medical Centres
A retail floor display that goes dark during trading hours is not a minor inconvenience. 50,000 hours rated panel life and 24/7 operating capability means the display runs through the duration of most commercial leases without planned replacement. IT managers push content updates to every display on the network without visiting each location.
Point of Sale Digital Displays for Retail Shopping Centres
Corporate lobby signage runs a simple requirement: on when the building opens, off when it closes. Scheduled power management handles that automatically. Content updates happen remotely without anyone visiting the display locations across the portfolio.
Key Features
- High-Brightness Panel for Ambient Light Environments: 50,000 hours continuous operation means this display can run 24/7 for over five years before reaching rated panel life. For commercial deployments where downtime creates operational disruption, that longevity removes planned replacement from the medium-term maintenance schedule.
- Sustained Visibility in High-Traffic Zones: 4K UHD at 55 inches provides enough resolution for close-proximity product showcase content. Packaging details, ingredient lists, and pricing information remain readable at 50cm to 2m viewing distances where lower-resolution panels would begin to show pixel structure.
- Scalable Fleet Deployment Architecture: LAN connectivity integrates the display into the managed commercial network rather than relying on WiFi signal strength at each installation point. For multi-display deployments across a facility, wired network connectivity simplifies content scheduling reliability.
Specifications
| Specification | Detail | Why It Matters |
|---|---|---|
| Panel Size | 55 inches | Determines effective viewing distance and content scale for the installation environment. |
| Native Resolution | 3840 × 2160 pixels (UHD) | Maintains sharp text and promotional content at typical customer interaction distances. |
| Aspect Ratio | 16:9 | |
| Brightness | 350 nits | Determines content legibility under ambient lighting — critical for window-facing, outdoor, and high-ambient installations. |
| Backlight Type | Edge-lit LED (ELED) | |
| Viewing Angle | 178° horizontal / 178° vertical | Maintains readability when mounted above counters, shelving, or walkways where viewers approach from multiple directions. |
| Operating Hours (MTBF) | 50,000 hours (24/7 operation rated) | Rated for sustained commercial operation — relevant for always-on deployments across retail trading and hospitality service hours. |
| Operating System | Android 5.1 | Supports standalone signage playback and app-based content management without requiring an external media player. |
| Content Management | Cybercast online advertising system | |
| Processor | Hi3751 V600 (Quad-core A53 CPU, Hexa-core GPU) | Suitable for interactive signage playback, touchscreen navigation, and lightweight commercial media applications. |
| Memory | 2GB DDR3 | |
| Storage | 8GB eMMC Flash | Provides onboard capacity for locally cached signage assets — supports playback continuity if network connectivity is interrupted. |
| Network Connectivity | Ethernet (RJ45) + Wi-Fi (802.11 b/g/n, 2.4GHz) | Ethernet and WiFi options provide flexibility for locations where running additional network cabling may not be practical. |
| Video Inputs | HDMI (1), Composite AV (Mini Jack) | |
| Video Output | HDMI Out (1) | |
| Control Interface | RS232 | |
| USB Ports | USB 3.0 (1), USB 2.0 (1) | Supports media playback from local storage and peripheral connectivity for interactive applications. |
| Expandable Storage | Micro SD card reader | Provides onboard capacity for locally cached signage assets — supports playback continuity if network connectivity is interrupted. |
| Audio Output | Line Out (1) | |
| VESA Mount | Supported | Compatible with standard commercial wall bracket systems — eliminates the need for proprietary mounting hardware. |
| Anti-Theft Lock | Kensington lock compatible | |
| Dimensions (W×H×D, without stand) | 1250.6 × 727 × 55 mm | Physical footprint determines bracket selection, wall cavity requirements, and clearance from adjacent surfaces. |
| Weight | 27.6 kg (approx.) | Installation weight determines bracket load rating and whether a two-person installation is required. |
| Operating Temperature | 0°C to +45°C | Temperature range determines safe geographic and seasonal deployment conditions for outdoor and semi-outdoor installations. |
| Operating Humidity | 10% to 90% (non-condensing) | |
| Storage Temperature | -20°C to +60°C | Provides onboard capacity for locally cached signage assets — supports playback continuity if network connectivity is interrupted. |
Warranty
This Soniq display is backed by a 1-year commercial warranty covering manufacturing defects. Contact Kickstart Computers for warranty claims and support.
