The TD2423 is engineered as a long-term infrastructure investment rather than a point-of-failure component. At 40,000 hours of operating life, this LED-backlit display provides predictable depreciation and reduces the total cost of ownership across multi-unit deployments. The lack of lamp replacement requirements — a core maintenance burden in legacy projection-based signage — removes a recurring operational task from your AV management workflow.
Key Features
- 10-Point IR Touchscreen: Infrared touch detection is more resistant to environmental interference than optical systems and remains responsive through dust, condensation, and thermal stress common in retail, transport, and hospitality environments. Touch registration is faster and more reliable across the full screen surface.
- Finger, Stylus, and Glove-Compatible Input: Operational flexibility in diverse venue contexts — healthcare staff in gloves, retail staff in winter conditions, or users carrying stylus-based transaction devices can all interact with the display without configuration changes. This reduces friction in deployment scenarios with varying user populations.
- Magnetic Pen Holder: Keeps interaction tools immediately available and prevents loss or damage during unattended operation. This is a practical detail in self-service and interactive kiosk deployments where the device is frequently accessed by different users.
- 40-Degree Adjustable Tilt: Ergonomic positioning in retail counters, information desks, and public-facing installations allows operators to minimize glare and optimize viewing angles for standing users. The range accommodates both angled counter mounting and near-vertical wall installation without requiring additional brackets.
- 7H Scratch-Resistant Screen: Hardened surface treatment resists accidental scuffs, fingerprints, and minor abrasions that degrade image clarity in high-traffic public environments. This directly extends visible lifespan and reduces the replacement schedule for cosmetic degradation.
- Dual Integrated Speakers: Built-in 2W × 2 audio output eliminates the need for separate speaker infrastructure in signage applications. This simplifies installation, reduces cable routing complexity, and ensures audio consistency across multi-display deployments.
Specifications
| Specification | Detail |
|---|---|
| Display Size | 24 inches (23.6 viewable area) |
| Resolution | 1920 × 1080 (Full HD) |
| Panel Type | VA, 16.9M colour support |
| Brightness | 250 cd/m² (typical) |
| Contrast Ratio | 3,000:1 static; 20M:1 dynamic |
| Operating Hours Rating | 40,000 hours minimum (lamp-free LED backlight) |
| Backlight Technology | LED (no lamp replacement required) |
| Touch Technology | Infrared (IR), 10-point multi-touch |
| Touch Compatibility | Finger, stylus, and gloved hand |
| Screen Surface | Glossy with 7H hardness coating (1.85 mm cover glass) |
| Response Time | 7 ms (GTG) |
| Viewing Angles | 178° horizontal, 178° vertical |
| Refresh Rate | 75 Hz |
| Operating System Support | Windows 7/8.1/10/11; macOS tested |
| Audio Output | Dual integrated speakers, 2W × 2 |
| Power Consumption | 15.5 W typical; 16.5 W max; 0.5 W standby |
| Power Supply | Internal; AC 100–240V |
| VESA Mount Compatibility | 100 × 100 mm |
| Physical Dimensions (W × H × D) | 571 × 348 × 101 mm with stand; 571 × 348 × 61 mm without stand |
| Weight | 5.2 kg net (4.7 kg without stand) |
| Tilt Range | 20° forward, 40° back |
| Certifications | Energy Star, EPEAT, FCC-B, CE, RoHS, WEEE |
Connectivity
- HDMI 1.4 (1x): Primary digital video input for content distribution systems and networked signage players. Supports 1920 × 1080 at 75 Hz.
- DVI-D (1x): Legacy digital video support for existing AV infrastructure or PC integration where HDMI distribution is unavailable.
- VGA (1x): Analog video input for compatibility with older signage controllers or PC outputs in retrofit installations.
- USB Type-B (1x): Touch controller interface and device management connection. Enables touch calibration and firmware updates.
- USB Type-A (2x): Peripheral connectivity for content distribution systems, remote management devices, or external storage devices in kiosk deployments.
- 3.5 mm Audio In (1x): External audio source input for integrated soundtrack or announcement playback.
- 3.5 mm Audio Out (1x): Audio output to external amplification if integrated speakers are insufficient for venue acoustics.
- Kensington Lock Slot (1x): Physical security provision for theft prevention in public-facing unattended installations.
Warranty
This ViewSonic display is covered by a 3-year replacement warranty. In the event of a verified hardware fault, ViewSonic will replace the unit, supporting reliable operation across commercial and signage deployments. Contact Kickstart Computers for warranty claims and support.
Looking for more options? Browse our full range of interactive digital signage solutions available from Kickstart Computers Australia.
