In retail stores, hospitality venues, and corporate lobbies, content consistency across multiple sites depends on reliable device scheduling and centralized control. The 50DP30FE addresses this directly with built-in cloud management via VisionInfo, allowing content updates and monitoring without physical access to individual displays.
Key Features
- 4K Resolution with Studio-Grade Color Accuracy: 3840 × 2160 resolution and 85% NTSC color coverage ensure fine detail visibility—critical where signage carries product information, promotional imagery, or wayfinding. The 1.07 billion color palette supports photo and video-heavy content libraries without color degradation.
- Anti-Glare Panel with Ambient Light Adaptation: The 25% haze coating and built-in light sensor automatically adjust brightness to surrounding conditions. In high-traffic retail and transport environments, this eliminates the need for manual brightness adjustment and maintains legibility throughout the day without oversaturation or dimming that requires operational oversight.
- Wide Viewing Angles for Passerby Engagement: 178° horizontal and vertical viewing angles keep content vivid from extreme angles—essential in retail aisles, museum corridors, and waiting areas where viewers approach from unpredictable directions.
- Flexible Orientation Support: Portrait and landscape modes allow deployment flexibility. Retail menu boards, directory signage, and vertical promotional displays maintain full 4K clarity regardless of orientation, reducing the need for multiple display SKUs across a deployment.
- VisionInfo Cloud Management Platform: Centralized scheduling, remote content updates, real-time device monitoring, and immediate alert systems mean content synchronization across multiple venues operates without on-site technician visits. Critical for chains and multi-site operators managing dozens of displays.
- 16/7 Operating Schedule: Designed for 16 hours daily operation across 7 days, the display and platform support extended retail and hospitality hours without requiring daily power cycling, reducing management overhead and improving content availability during peak traffic periods.
- Compact Footprint with Minimal Bezel: At 1110 × 649mm with 2.3mm side bezels and 8.3mm top bezel, the display integrates cleanly into retail shelving, wall mounts, and kiosk installations. Minimal bezels reduce visual fragmentation in multi-display arrays.
Specifications
| Specification | Detail |
|---|---|
| Display Size | 50 inches |
| Panel Type | VA, DLED backlight |
| Resolution | 3840 × 2160 (4K UHD) |
| Brightness | 350 nits (typical) |
| Contrast Ratio | 5000:1 (typical) |
| Color Gamut | 85% NTSC, 1.07 billion colors |
| Viewing Angles | 178° horizontal / 178° vertical |
| Refresh Rate | 60Hz |
| Response Time | 8ms (typical) |
| Haze / Anti-Glare | 25% haze coating |
| Operating System | Android 9 |
| Memory | 2GB DDR4 |
| Storage | 16GB eMMC |
| Orientation | Landscape and portrait |
| Operating Hours | 16 hours daily, 7 days per week |
| Panel Lifespan | Up to 30,000 hours |
| Built-In Speaker | 2 × 10W |
| Dimensions (WxHxD) | 1110 × 649 × 77.2mm |
| Bezel Width | Top: 8.3mm, Left/Right: 2.3mm, Bottom: 15mm |
| Net Weight | 10.5kg |
| VESA Mount Pattern | 300mm × 300mm |
| Power Supply | AC 100–240V, 50/60Hz |
| Power Consumption (Typical) | 90W |
| Power Consumption (Maximum) | 140W |
| Standby Power Draw | <0.5W |
| Operating Temperature | 0°C to 40°C |
| Operating Humidity | 10% to 80% (non-condensing) |
| Certifications | CB, CE, ERP, cTUVus, CEC, FCC (Class B), Energy Star 8.0 |
| IP Rating | IP5X |
Connectivity
- HDMI 2.0: 3 inputs for direct content source connections or daisy-chaining with external distribution equipment.
- USB 2.0 Type-A: 2 ports for local media playback, firmware updates, and peripheral connections.
- LAN (RJ45): 1 Gigabit Ethernet port for VisionInfo cloud platform connectivity and device management.
- RS232 (RJ45): 1 port for control system integration and legacy device automation protocols.
- 3.5mm Audio Output: 1 stereo output for external amplification if on-display speaker output is insufficient.
- WiFi 802.11a/b/g/n/ac (Dual-Band 2.4/5.0GHz): Wireless network access for VisionInfo cloud management and content scheduling when wired LAN is not available.
- Bluetooth 5.1: Wireless peripheral support for remote controls and mobile device pairing.
This commercial digital signage display fits naturally into larger networked signage infrastructure deployments across retail chains, hospitality groups, and multi-site corporate environments. For deployment options and additional product selection guidance, see our Commercial Digital Signage Displays.
